ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm

Name: ER110SG ER80G Gmaw Welding Wire Mig Mag 10mm
Brand: LONGTENG
Price: 1 USD

China ER110S-G ER80-G Gmaw Welding Wire Mig Mag 1.0mm wholesale

Brand Name : LONGTENG

Model Number : LT·ER80-G

Certification : TUV CE, ABS, DB, ISO9001

Place of Origin : CHINA

MOQ : one pallet

Price : USD 1

Supply Ability : 1,200,000 TON PER YEAR

Delivery Time : 15 WORKING DAYS

Packaging Details : Neutral box/ LT color box/OEM brand box

Product name : High Strength Steel Solid Welding Wire LT·ER80-G

Model : LT·ER80-G (ER110S-G)

Brand : LONGTENG

Diameter : 0.8/0.9/1.0/1.2/1.6mm

Weight : 1/5/15/20kg

Surface : Cooper plating

Spool material : Black plastic spool

Packing : Color box

OEM : Accept

Diameter of spool : 100/200/270/300mm

Contact Now

LT·ER80-G 0.8/1.0/1.2/1.6mm High Strength Steel Solid Welding Wire

LT·ER80-G Conform to Standard :GB/T 8110 ER80-G

AWS ER110S-G

Features and Applications:
1. ER110S-G is low alloyed and high strength GMAW wire and GTAW rods
2. It is used for joining of the high strength low alloy steels and the fine grained constructional steels with minimum yield strength of 690 N/mm²,

3. especially Hardox and Weldox sheets
4. Boilers, pressure vessels, pipelines, structure steels are the other application areas
5. Weld metal has high impact and toughness at low temperatures
6. Pre-heat can be according to the base material
7. Shielding gases - MAG : (Ar+% 15-25 CO2) / TIG : (Ar)

Chemical Composition(%)

Chemical Composition	C	Mn	Si	S	P	Cr	Ni	Mo	Cu
Guarantee Value	≤0.11	1.40~	0.40~	≤0.025	≤0.025	0.25~	1.20~	0.20~	≤0.50
Guarantee Value	≤0.11	1.85	1	≤0.025	≤0.025	0.6	2.4	0.6	≤0.50

Mechanical Properties of Deposited Metal(Ar+20%CO2)

Test Item	R_m(MPa)	R_eL/R_p0.2(MPa)	A(%)	KV₂(J)
Test Item	R_m(MPa)	R_eL/R_p0.2(MPa)	A(%)	-20℃
Guarantee Value	≥790	≥690	≥17	≥27
General Result	840	730	24.5	85,93,75

Notes:

1. Shield gas: Must ensure not to operate with impurity shield Gas

2. Operation flow rate of shield gas: 20-25L/min.

3. Electrode extension: 15-25mm
